Scaffold an MCP Server

Outcome

Use the Codex app's MCP-building skill to plan a minimal TypeScript MCP server, then create the local package with the stable SDK and stdio transport.

This course uses the Codex app plus a local stdio server because that is the fastest way for business operators to learn Codex by creating a capability for it. Remote MCP servers are useful later, but they add auth, deployment, and network concerns before the core tool contract is clear.

OpenAI's Codex MCP documentation supports both local stdio MCP servers and streamable HTTP servers. This lesson uses stdio first so the learner can see the package, command, build output, and protocol boundary before adding deployment complexity.

1) Start with the Codex MCP-building skill

In the Codex app, start the build with a prompt like this:

Use the MCP-building skill to help me create a local TypeScript stdio MCP server named codex-demo-mcp.

The first workflow is read-only: search RapidAPI Local Business Data for businesses and return structured records for operator review.

Keep the server narrow, use the TypeScript MCP SDK, use Zod schemas, return structuredContent, include read-only annotations, and give actionable error messages.

Use the skill output as a build plan and review checklist. The learner should still create the files below and understand the tool contract.

Before accepting the plan, check that Codex has answered four operator questions:

• What files will be created?
• What command starts the server?
• What will Codex be allowed to call?
• What evidence proves the empty server works?

2) Create the Package

mkdir -p packages/codex-demo-mcp/src
cd packages/codex-demo-mcp

Create package.json:

{
  "name": "@create-something/codex-demo-mcp",
  "version": "0.1.0",
  "private": true,
  "type": "module",
  "bin": {
    "codex-demo-mcp": "./dist/index.js"
  },
  "main": "dist/index.js",
  "scripts": {
    "build": "tsc",
    "dev": "tsc --watch",
    "start": "node dist/index.js"
  },
  "dependencies": {
    "@modelcontextprotocol/sdk": "^1.29.0",
    "zod": "^4.4.3"
  },
  "devDependencies": {
    "@types/node": "^22.0.0",
    "typescript": "^5.9.0"
  }
}

If this is a new workspace package, add dist/ to the nearest .gitignore.

Create tsconfig.json:

{
  "extends": "../../tsconfig.base.json",
  "compilerOptions": {
    "outDir": "./dist",
    "rootDir": "./src",
    "module": "NodeNext",
    "moduleResolution": "NodeNext",
    "target": "ES2022",
    "strict": true
  },
  "include": ["src/**/*"]
}

3) Add the Server Entry Point

Create src/index.ts:

#!/usr/bin/env node
import { McpServer } from '@modelcontextprotocol/sdk/server/mcp.js';
import { StdioServerTransport } from '@modelcontextprotocol/sdk/server/stdio.js';

const server = new McpServer({
  name: 'codex-demo-mcp',
  version: '0.1.0'
});

const transport = new StdioServerTransport();
await server.connect(transport);

Stdio MCP servers reserve stdout for protocol messages. Send diagnostics to stderr with console.error, or Codex may see corrupted protocol output.

Keep operating guidance in tool names, descriptions, schemas, and error messages. Those are the surfaces Codex will inspect when deciding how to use the server.

4) Install and Build

From repo root:

pnpm install
pnpm --filter @create-something/codex-demo-mcp build

If build passes, your skeleton is ready.

Checkpoint

You have not built a useful MCP yet. You have built the smallest stable shell:

• one package;
• one executable entry point;
• one stdio transport;
• no side effects;
• no hidden credentials.

Official References Used

• Model Context Protocol in Codex: Codex support for stdio MCP servers, HTTP MCP servers, and instructions.
• Codex config basics: where Codex reads user and project configuration.
• Codex config reference: searchable reference for config.toml keys and MCP server configuration.

Next

Continue to Add Your First Tool.
